• 45 mm Cylindrical Roller Bearing with double rib inner ring, single rib and 1 retaining ring in outer ring and formed steel retainer

Dimensions

Outside Diameter (mm)	100 mm
Bore Size (mm)	45 mm

Technical Specifications

C Dynamic Load Rating	CALL ENG lb
Inner Ring Rib Outside Diameter (mm)	64.31 mm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	59.41 mm
Inner Ring Type	Double Rib (U)
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	90.4 mm
Inner Ring Bore Radius (mm)	1.52 mm
Retainer Type	SEE DESCRIPTION
Vibration Frequency Fundamental Train	CALL ENG cps
Outer Ring Rib Inside Diameter (mm)	81.48 mm
Series Weight	Medium (3)
Maximum Speed (RPM)	CALL ENG rpm
Mounted Clearance	SEE DESCRIPTION
Shaft Locking	DIRECT SHAFT MOUNT
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	59.2 mm
Product	Series 1300 Unmounted Bearings
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)
Vibration Frequency Inner Ring Defect	CALL ENG cps
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	55.9 mm
Co Static Load Rating	CALL ENG lb
Inner Ring and Roller Assembly Over Roller Diameter (mm)	86.06 mm
Inner Ring Raceway Outside Diameter (mm)	59.36 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	85.8 mm
Ring Width Series	Narrow (1)
Bearing Width (mm)	25 mm
Basic Bearing Number	1309
Series	Unmounted Bearings
Vibration Frequency Roller Spin	CALL ENG cps
Rolling Element	Cylindrical
Vibration Frequency Outer Ring Defect	CALL ENG cps
Outer Ring Raceway Inside Diameter (mm)	86.1 mm

General Specifications

UPC	662327058111
Weight	2.11 LB
HTC	8482500000
Country of Origin	Mexico
