Dimensions

Bore Size (mm)	40 mm
Outside Diameter (mm)	80 mm

Technical Specifications

Retainer Type	SEE DESCRIPTION
Vibration Frequency Outer Ring Defect	CALL ENG cps
Series Weight	Light (2)
Inner Ring Rib Outside Diameter (mm)	53.44 mm
Vibration Frequency Roller Spin	CALL ENG cps
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	69.6 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	69.58 mm
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	49.8 mm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	72.9 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
Outer Ring and Roller Assembly Under Roller Diameter (mm)	49.97 mm
Product	Series 1200 Unmounted Bearings
Maximum Speed (RPM)	CALL ENG rpm
Outer Ring Rib Inside Diameter (mm)	66.42 mm
Bearing Width (mm)	18 mm
Vibration Frequency Fundamental Train	CALL ENG cps
Ring Width Series	Narrow (1)
Inner Ring Raceway Outside Diameter (mm)	49.93 mm
Outer Ring Raceway Inside Diameter (mm)	69.62 mm
Co Static Load Rating	CALL ENG lb
Inner Ring Type	Double Rib (U)
Series	Unmounted Bearings
Mounted Clearance	SEE DESCRIPTION
C Dynamic Load Rating	CALL ENG lb
Inner Ring Bore Radius (mm)	1.52 mm
Basic Bearing Number	1208
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	47.2 mm
Rolling Element	Cylindrical

General Specifications

UPC	662327715533
Weight	0.94 LB
HTC	8482500000
Country of Origin	Mexico
