Dimensions

Bore Size (mm)	75 mm
Outside Diameter (mm)	115 mm

Technical Specifications

Vibration Frequency Inner Ring Defect	CALL ENG cps
Co Static Load Rating	CALL ENG lb
Inner Ring Raceway Outside Diameter (mm)	85.23 mm
Outer Ring Raceway Inside Diameter (mm)	104.94 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	104.9 mm
Inner Ring Bore Radius (mm)	2.03 mm
Inner Ring Rib Outside Diameter (mm)	89.15 mm
Maximum Speed (RPM)	CALL ENG rpm
Mounted Clearance	SEE DESCRIPTION
Series Weight	Extra Light (0)
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	85.1 mm
Outer Ring Type	Single Rib Outer Ring (D)
Vibration Frequency Roller Spin	CALL ENG cps
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	108.4 mm
Series	Unmounted Bearings
Ring Width Series	Narrow (1)
Basic Bearing Number	1015
Outer Ring Rib Inside Diameter (mm)	101.02 mm
Bearing Width (mm)	20 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	82.6 mm
C Dynamic Load Rating	CALL ENG lb
Rolling Element	Cylindrical
Vibration Frequency Fundamental Train	CALL ENG cps
Inner Ring Type	Double Rib (U)
Product	Series 1000 Unmounted Bearings
Retainer Type	SEE DESCRIPTION

General Specifications

UPC	662327056698
Weight	1.67 LB
HTC	8482500000
Country of Origin	Mexico
