• Consult Application Engineering

Dimensions

Bore Size (mm)	65 mm
Outside Diameter (mm)	140 mm

Technical Specifications

Vibration Frequency Fundamental Train	CALL ENG cps
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	78.7 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Inner Ring Bore Radius (mm)	2.54 mm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	83.73 mm
Basic Bearing Number	1313
Outer Ring Rib Inside Diameter (mm)	114.68 mm
Inner Ring Rib Outside Diameter (mm)	90.7 mm
Vibration Frequency Roller Spin	CALL ENG cps
Outer Ring Type	Double Rib Outer Ring (E)
Outer Ring Raceway Inside Diameter (mm)	121.37 mm
Product	Series 1300 Unmounted Bearings
Inner Ring Type	Short - Single Rib With Inner Ring Side Plate (SN)
Series Weight	Medium (3)
Series	Unmounted Bearings
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	121.2 mm
Mounted Clearance	SEE DESCRIPTION
Bearing Width (mm)	33 mm
Co Static Load Rating	CALL ENG lb
Inner Ring Raceway Outside Diameter (mm)	83.68 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
Ring Width Series	Narrow (1)
Maximum Speed (RPM)	CALL ENG rpm
Rolling Element	Cylindrical
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	83.6 mm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	127 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	121.31 mm
C Dynamic Load Rating	CALL ENG lb
Retainer Type	SEE DESCRIPTION

General Specifications

UPC	662327056568
Weight	5.47 LB
HTC	8482500000
Country of Origin	Mexico
