Dimensions

Bore Size (mm)	70 mm
Outside Diameter (mm)	125 mm

Technical Specifications

Ring Width Series	Wide (5)
Inner Ring Type	Single Rib (R)
Vibration Frequency Inner Ring Defect	CALL ENG cps
Maximum Speed (RPM)	CALL ENG rpm
Series	Unmounted Bearings
Series Weight	Light (2)
Bearing Width (mm)	39.69 mm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	115.6 mm
C Dynamic Load Rating	CALL ENG lb
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	81.8 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	111.5 mm
Inner Ring Bore Radius (mm)	2.54 mm
Basic Bearing Number	5214
Vibration Frequency Fundamental Train	CALL ENG cps
Vibration Frequency Roller Spin	CALL ENG cps
Inner Ring and Roller Assembly Over Roller Diameter (mm)	111.47 mm
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	84.6 mm
Outer Ring Raceway Inside Diameter (mm)	111.54 mm
Product	Series 5200 Unmounted Bearings
Outer Ring Rib Inside Diameter (mm)	107.01 mm
Inner Ring Rib Outside Diameter (mm)	89.61 mm
Inner Ring Raceway Outside Diameter (mm)	84.77 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Co Static Load Rating	CALL ENG lb
Rolling Element	Cylindrical
Retainer Type	SEE DESCRIPTION
Mounted Clearance	SEE DESCRIPTION
Outer Ring and Roller Assembly Under Roller Diameter (mm)	84.84 mm
Outer Ring Type	Double Rib Outer Ring (E)

General Specifications

UPC	793699001297
Weight	4.83 LB
HTC	8482400000
Country of Origin	Mexico
