• 85 mm Cylindrical Roller Bearing with single rib inner ring, double rib outer ring and segmented retainer, Special internal clearance of .0086" to .0102"

Dimensions

Outside Diameter (mm)	130 mm
Bore Size (mm)	85 mm

Technical Specifications

C Dynamic Load Rating	CALL ENG lb
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	118.6 mm
Co Static Load Rating	CALL ENG lb
Rolling Element	Cylindrical
Bearing Width (mm)	22 mm
Bore Type	Straight
Vibration Frequency Roller Spin	CALL ENG cps
Outer Ring Rib Inside Diameter (mm)	114.48 mm
Inner Ring Bore Radius (mm)	2.03 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Inner Ring Type	Single Rib (R)
Inner Ring Rib Outside Diameter (mm)	100.63 mm
Maximum Speed (RPM)	CALL ENG rpm
Product	Series 1000 Unmounted Bearings
Outer Ring Type	Double Rib Outer Ring (E)
Series Weight	Extra Light (0)
Vibration Frequency Inner Ring Defect	CALL ENG cps
Vibration Frequency Fundamental Train	CALL ENG cps
Shaft Locking	DIRECT SHAFT MOUNT
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	122.7 mm
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	93.5 mm
Inner Ring Raceway Outside Diameter (mm)	96.32 mm
Series	Unmounted Bearings
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	96.3 mm
Outer Ring Raceway Inside Diameter (mm)	118.17 mm
Ring Width Series	Narrow (1)
Retainer Type	SEE DESCRIPTION
Basic Bearing Number	1017
Mounted Clearance	SEE DESCRIPTION

General Specifications

UPC	662327687267
Weight	2.30 LB
HTC	8482500000
Country of Origin	Mexico
