• 1 15/16" Mounted Ball Bearing, Medium Duty, Cast Iron 2-Bolt Pillow Block, Centrik-Lok CL Locking Device, Single Lip Contact Seal

Dimensions

Overall Height (in)	5.09 in
Base to Center Height (in)	2.5000 in
Base Width (in)	2.88 in
Length Through Bore (in)	2.25 in
Overall Width (in)	2.88 in
Overall Length (in)	9.5 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	1.9375 in
Foot Height (in)	1 in
Bolt Spacing (in)	6.75 in
Centerline to Outermost Bearing Face (in)	1.38 in

Technical Specifications

Housing Base	Semi-Solid
Housing Style	Pillow Block
Misalignment Type	Static Only
Bore Shape	Straight
Slot Length (in)	1.22 in
Housing Construction	One Piece
Seal Type	Single Lip Contact Seal
Housing Color	Black
Rolling Element	Ball Bearing
Outer Ring Land Profile	Standard
Housing Type	Pillow Block, Two Bolt
Cage Material	Molded fiber glass reinforced nylon
Locking Collar Outside Diameter (in)	3.50 in
Setscrew Torque (in-lbs)	313-348 in/lbs
Ability to Relubricate	Yes
Max Operating Temperature (C)	107 °C
Max Operating Temperature (F)	225 °F
Inner Ring Outside Diameter (in)	2.749 in
Radial Clearance	C3 STANDARD
Vibration Frequency Roller Spin	0.0437 cps
Insert	MCLG231NLPA
Locking Device Kit	CL2355S
Bearing Type	Medium Duty
Dynamic Load Rating (lb)	9,752 lb
Vibration Frequency Inner Ring Defect	0.0987 cps
Housing Coating	Powder Coated
Bearing Insert Material	52100 Bearing Steel
Cage Type	Ball Riding Retainer
Grease Fitting Thread Size	1/8 NPT
Bearing Brand	LINK-BELT MEDIUM DUTY BALL
Shaft Locking Type	Concentric
Vibration Frequency Fundamental Train	0.0068 cps
Vibration Frequency Outer Ring Defect	0.0680 cps
End Cap Available	No
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	4360 rpm
Static Load Rating (lb)	6,570 lb
Size Code	211
Housing Material	Cast Iron
Misalignment Capability	±2.0° Misalignment - Static Only
Lubricant	EXXON RONEX MP STD
Bearing Insert Finish	Black Oxide
Base Length (in)	9.50 in

General Specifications

UPC	662864823302
Weight	8.05 LB
Packaged Length	5.13 IN
Packaged Width	2.63 IN
Packaged Height	9.00 IN
HTC	8483208040
Country of Origin	Mexico
