• 75 mm Cylindrical Roller Bearing with plain cylindrical inner ring, double rib outer ring and segmented retainer

Dimensions

Outside Diameter (mm)	160 mm
Bore Size (mm)	75 mm

Technical Specifications

Rolling Element	Cylindrical
Vibration Frequency Inner Ring Defect	CALL ENG cps
Vibration Frequency Roller Spin	CALL ENG cps
Outer Ring Rib Inside Diameter (mm)	131.37 mm
Product	Series 5300 Unmounted Bearings
Co Static Load Rating	CALL ENG lb
Outer Ring and Roller Assembly Under Roller Diameter (mm)	95.99 mm
Mounted Clearance	SEE DESCRIPTION
Outer Ring Type	Double Rib Outer Ring (E)
Inner Ring Raceway Outside Diameter (mm)	95.92 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	139.07 mm
Outer Ring Raceway Inside Diameter (mm)	139.14 mm
Series	Unmounted Bearings
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	138.9 mm
Inner Ring Rib Outside Diameter (mm)	104.04 mm
Retainer Type	SEE DESCRIPTION
Ring Width Series	Wide (5)
Bore Type	Straight
Bearing Width (mm)	68.262 mm
Series Weight	Medium (3)
Shaft Locking	DIRECT SHAFT MOUNT
Vibration Frequency Fundamental Train	CALL ENG cps
Basic Bearing Number	5315
C Dynamic Load Rating	CALL ENG lb
Inner Ring Type	Plain Cylindrical (A)
Vibration Frequency Outer Ring Defect	CALL ENG cps
Inner Ring Bore Radius (mm)	2.03 mm
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	95.8 mm
Maximum Speed (RPM)	CALL ENG rpm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	145.8 mm
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	90.4 mm

General Specifications

UPC	662327053826
Weight	15.26 LB
HTC	8482500000
Country of Origin	Mexico
