• 70 mm Cylindrical Roller Bearing with plain cylindrical inner ring, double rib outer ring and segmented retainer

Dimensions

Outside Diameter (mm)	150 mm
Bore Size (mm)	14 - 70 mm

Technical Specifications

Outer Ring Raceway Inside Diameter (mm)	129.38 mm
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	84.3 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	129.31 mm
Series	Unmounted Bearings
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	89.2 mm
Shaft Locking	DIRECT SHAFT MOUNT
Co Static Load Rating	CALL ENG lb
Retainer Type	SEE DESCRIPTION
Outer Ring Type	Double Rib Outer Ring (E)
C Dynamic Load Rating	CALL ENG lb
Mounted Clearance	SEE DESCRIPTION
Vibration Frequency Inner Ring Defect	CALL ENG cps
Vibration Frequency Roller Spin	CALL ENG cps
Product	Series 5300 Unmounted Bearings
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	135.6 mm
Inner Ring Type	Plain Cylindrical (A)
Inner Ring Bore Radius (mm)	2.03 mm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	89.26 mm
Rolling Element	Cylindrical
Basic Bearing Number	5314
Inner Ring Rib Outside Diameter (mm)	96.72 mm
Bearing Width (mm)	63.6 mm
Inner Ring Raceway Outside Diameter (mm)	89.19 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	129.3 mm
Ring Width Series	Wide (5)
Vibration Frequency Outer Ring Defect	CALL ENG cps
Outer Ring Rib Inside Diameter (mm)	122.2 mm
Vibration Frequency Fundamental Train	CALL ENG cps
Maximum Speed (RPM)	CALL ENG rpm
Series Weight	Medium (3)

General Specifications

UPC	662327643386
Weight	12.46 LB
HTC	8482500000
Country of Origin	Mexico
