• 50 mm Cylindrical Roller Bearing with plain cylindrical inner ring, 2 retaining rings in outer ring and formed steel retainer

Dimensions

Outside Diameter (mm)	110 mm
Bore Size (mm)	50 mm

Technical Specifications

Outer Ring Rib Inside Diameter (mm)	89.36 mm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	99.1 mm
Inner Ring Type	Plain Cylindrical (A)
Ring Width Series	Wide (5)
Mounted Clearance	SEE DESCRIPTION
Bore Type	Straight
Outer Ring and Roller Assembly Under Roller Diameter (mm)	65.19 mm
Maximum Speed (RPM)	CALL ENG rpm
Inner Ring Rib Outside Diameter (mm)	70.64 mm
Inner Ring Raceway Outside Diameter (mm)	65.15 mm
Series	Unmounted Bearings
Rolling Element	Cylindrical
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	94.5 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	94.44 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
Vibration Frequency Roller Spin	CALL ENG cps
Retainer Type	SEE DESCRIPTION
Shaft Locking	DIRECT SHAFT MOUNT
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	65 mm
Product	Series 5300 Unmounted Bearings
Outer Ring Raceway Inside Diameter (mm)	94.49 mm
Vibration Frequency Fundamental Train	CALL ENG cps
Co Static Load Rating	CALL ENG lb
Vibration Frequency Outer Ring Defect	CALL ENG cps
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	61 mm
Series Weight	Medium (3)
Outer Ring Type	Outer Ring With Two Retaining Rings in I.D. (T)
Basic Bearing Number	5310
Inner Ring Bore Radius (mm)	2.03 mm
C Dynamic Load Rating	CALL ENG lb
Bearing Width (mm)	44.45 mm

General Specifications

UPC	662327053697
Weight	4.28 LB
HTC	8482500000
Country of Origin	Mexico
