• 45 mm Cylindrical Roller Bearing with plain cylindrical inner ring, double rib outer ring and segmented retainer, Special internal clearance of .0012" to .0022"

Dimensions

Bore Size (mm)	45 mm
Outside Diameter (mm)	100 mm

Technical Specifications

Series	Unmounted Bearings
Inner Ring Rib Outside Diameter (mm)	64.31 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	85.8 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
Inner Ring Bore Radius (mm)	2.03 mm
Basic Bearing Number	5309
Ring Width Series	Wide (5)
Inner Ring Type	Plain Cylindrical (A)
Maximum Speed (RPM)	CALL ENG rpm
Retainer Type	SEE DESCRIPTION
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	90.4 mm
Vibration Frequency Fundamental Train	CALL ENG cps
Co Static Load Rating	CALL ENG lb
Vibration Frequency Roller Spin	CALL ENG cps
Outer Ring Rib Inside Diameter (mm)	81.48 mm
Series Weight	Medium (3)
Mounted Clearance	SEE DESCRIPTION
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	59.2 mm
C Dynamic Load Rating	CALL ENG lb
Shaft Locking	DIRECT SHAFT MOUNT
Outer Ring Type	Double Rib Outer Ring (E)
Bore Type	Straight
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	55.9 mm
Product	Series 5300 Unmounted Bearings
Outer Ring Raceway Inside Diameter (mm)	86.1 mm
Bearing Width (mm)	39.69 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	86.06 mm
Vibration Frequency Outer Ring Defect	CALL ENG cps
Inner Ring Raceway Outside Diameter (mm)	59.36 mm
Rolling Element	Cylindrical
Outer Ring and Roller Assembly Under Roller Diameter (mm)	59.41 mm

General Specifications

UPC	793699024609
Weight	3.49 LB
HTC	8482500000
Country of Origin	Mexico
