• 55 mm Cylindrical Roller Bearing with plain cylindrical inner ring, double rib outer ring and segmented retainer, Special internal clearance of .0014" to .0026"

Dimensions

Bore Size (mm)	55 mm
Outside Diameter (mm)	100 mm

Technical Specifications

Co Static Load Rating	CALL ENG lb
Bearing Width (mm)	33.34 mm
Product	Series 5200 Unmounted Bearings
Shaft Shoulder Diameter (Ribbed Inner Ring) [Min] (mm)	66.8 mm
Inner Ring Raceway Outside Diameter (mm)	66.9 mm
Basic Bearing Number	5211
Outer Ring Rib Inside Diameter (mm)	84.53 mm
Outer Ring Raceway Inside Diameter (mm)	88.02 mm
Inner Ring Rib Outside Diameter (mm)	70.74 mm
Vibration Frequency Fundamental Train	CALL ENG cps
Series Weight	Light (2)
Vibration Frequency Inner Ring Defect	CALL ENG cps
C Dynamic Load Rating	CALL ENG lb
Vibration Frequency Outer Ring Defect	CALL ENG cps
Retainer Type	SEE DESCRIPTION
Ring Width Series	Wide (5)
Rolling Element	Cylindrical
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	87.9 mm
Outer Ring Type	Double Rib Outer Ring (E)
Inner Ring Bore Radius (mm)	2.03 mm
Inner Ring Type	Plain Cylindrical (A)
Series	Unmounted Bearings
Maximum Speed (RPM)	CALL ENG rpm
Outer Ring and Roller Assembly Under Roller Diameter (mm)	66.96 mm
Mounted Clearance	SEE DESCRIPTION
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	91.4 mm
Inner Ring and Roller Assembly Over Roller Diameter (mm)	87.96 mm
Vibration Frequency Roller Spin	CALL ENG cps
Shaft Shoulder Diameter (Plain Inner Ring) [Min] (mm)	64 mm
Shaft Locking	DIRECT SHAFT MOUNT

General Specifications

UPC	662327690007
Weight	2.54 LB
HTC	8482500000
Country of Origin	Mexico
