• Link-Belt M1208UV Cylindrical Roller Bearings Series 1200 Outer Ring and Roller Assembly. Contact Rexnord for more details.

Dimensions

Outside Diameter (mm)

80 mm

Technical Specifications

Vibration Frequency Fundamental Train	CALL ENG cps
Outer Ring and Roller Assembly Under Roller Diameter (mm)	49.97 mm
Rolling Element	Cylindrical
Vibration Frequency Inner Ring Defect	CALL ENG cps
Bore Type	Straight
Vibration Frequency Outer Ring Defect	CALL ENG cps
Co Static Load Rating	CALL ENG lb
C Dynamic Load Rating	CALL ENG lb
Retainer Type	SEE DESCRIPTION
Outer Ring Raceway Inside Diameter (mm)	69.62 mm
Outer Ring Rib Inside Diameter (mm)	66.42 mm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	72.9 mm
Series	Outer Ring & Roller Assemblies
Basic Bearing Number	1208
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	69.6 mm
Maximum Speed (RPM)	CALL ENG rpm
Mounted Clearance	SEE DESCRIPTION
Series Weight	Light (2)
Vibration Frequency Roller Spin	CALL ENG cps
Ring Width Series	Narrow (1)
Bearing Width (mm)	18 mm
Product	Series 1200 Outer Ring & Roller Assemblies
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)

General Specifications

UPC	662327105877
Weight	0.65 LB
HTC	8482500000
Country of Origin	Mexico
