• Link-Belt M1206UVW140 Cylindrical Roller Bearings Series 1200 Outer Ring and Roller Assembly. Contact Rexnord for more details.

Dimensions

Outside Diameter (mm)

62 mm

Technical Specifications

Series	Outer Ring & Roller Assemblies
Outer Ring and Roller Assembly Under Roller Diameter (mm)	38.1 mm
Co Static Load Rating	CALL ENG lb
Outer Ring Rib Inside Diameter (mm)	51.48 mm
Housing Shoulder Diameter (Ribbed Outer Ring) [Max] (mm)	53.8 mm
Vibration Frequency Inner Ring Defect	CALL ENG cps
Rolling Element	Cylindrical
Vibration Frequency Outer Ring Defect	CALL ENG cps
C Dynamic Load Rating	CALL ENG lb
Series Weight	Light (2)
Outer Ring Raceway Inside Diameter (mm)	54.07 mm
Maximum Speed (RPM)	CALL ENG rpm
Housing Shoulder Diameter (Plain Outer Ring) [Max] (mm)	56.4 mm
Vibration Frequency Roller Spin	CALL ENG cps
Bearing Width (mm)	16 mm
Outer Ring Type	Single Rib Outer Ring One Retaining Ring in I.D. (U)
Retainer Type	SEE DESCRIPTION
Basic Bearing Number	1206
Product	Series 1200 Outer Ring & Roller Assemblies
Ring Width Series	Narrow (1)
Mounted Clearance	SEE DESCRIPTION
Vibration Frequency Fundamental Train	CALL ENG cps

General Specifications

UPC	662327105785
Weight	0.38 LB
HTC	8482500000
Country of Origin	Mexico
