• 2-3/16" Mounted Spherical Roller Bearing, Expansion Cast Iron Flange Block, Single Setscrew Locking Collar, Clearance Seal

Dimensions

Bore Diameter (in)	2.1875 in
Overall Length (in)	7.75 in
Overall Width (in)	7.75 in
Overall Height (in)	3.41 in
Foot Height (in)	0.69 in
Bolt Size (in)	5/8 in
Locking Collar Outside Diameter (in)	3.25 in
Standoff Distance (in)	0.09 in
Housing Outside Diameter (in)	7.75 in
Bolt Circle (in)	6.375 in
Bolt Spacing (in)	4.5 in
Expansion Capability (in)	0.38 in
Length Through Bore (in)	3.31 in
Housing Cast Face to Outermost Bearing Face (in)	0.78 in
Inner Ring Outside Diameter (in)	2.62 in

Technical Specifications

Fixed/Expansion	Expansion
Housing Style	Flange Block
Radial Dynamic Load Capacity (lb)	32,500 lb
Housing Type	Flange, Four Bolt
Radial Clearance	C0 STANDARD
Housing Material	Cast Iron
Series	Flange Blocks
Rolling Element	Spherical Roller
Cage Material	Steel
Housing Construction	Solid
Seal Type	Clearance Seal
Shaft Locking Type	Single Set Collar
Misalignment Type	Dynamic
Static Load Rating (lb)	44,400 lb
Product	FEB22400
Available Seal Type	E Lip Seal; H Labyrinth Seal; E7 Triple Lip Seal
Ability to Relubricate	Yes
Seal Kit	B436HS
Maximum Speed (RPM)	2500 rpm
Setscrew Torque (in-lbs)	460 in/lbs
Size Code	B436
Housing Coating	POWDER COATED
Vibration Frequency Outer Ring Defect	0.1377 cps
Locking Device Kit	B436SC
Misalignment Capability	±2.0° Misalignment - Dynamic
Vibration Frequency Roller Spin	0.0606 cps
Primary Seal	STEEL CLEARANCE SEAL
Vibration Frequency Fundamental Train	0.0072 cps
Vibration Frequency Inner Ring Defect	0.179 cps
Expansion Lock Plug	B224408A
Lubricant	EXXON RONEX MP STD
Max Operating Temperature (F)	225 °F
Insert	CSEB22435H
Grease Fitting Thread Size	1/8 NPT
Max Operating Temperature (C)	107 °C

General Specifications

UPC	662327030285
Weight	14.00 LB
Packaged Length	7.75 IN
Packaged Width	3.69 IN
Packaged Height	7.88 IN
HTC	8483204080
Country of Origin	Mexico
