• 1" Mounted Ball Bearing, Intermediate Duty, Cast Iron 3-Bolt Bracket Flange Block, Setscrew Locking, Single Lip Contact Seal

Dimensions

Overall Length (in)	4.75 in
Foot Height (in)	0.38 in
Bolt Size (in)	3/8 in
Overall Width (in)	2.75 in
Overall Height (in)	1.53 in
Length Through Bore (in)	1.178 in
Base to Center Height (in)	3.38 in
Bore Diameter (in)	1 in
Bolt Spacing (in)	1.6250 in

Technical Specifications

Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	Molded fiber glass reinforced nylon
Pilot Configuration	No Pilot
Seal Type	Single Lip Contact Seal
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Style	Flange Block
Misalignment Type	Static Only
Housing Type	Flange, Bracket, Three Bolt
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	85 in/lbs
Vibration Frequency Outer Ring Defect	0.0595 cps
Size Code	205
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	C3 STANDARD
Misalignment Capability	±1.5° Misalignment - Static Only
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0387 cps
Max Operating Temperature (F)	225 °F
Bolt Spacing Height Direction (in)	1.125 in
Bearing Type	Intermediate Duty
Max Operating Temperature (C)	107 °C
End Cap Available	No
Housing Material	Cast Iron
Bearing Brand	LINK-BELT 200 SERIES BALL
Maximum Speed (RPM)	6800 rpm
Dynamic Load Rating (lb)	3,150 lb
Inner Ring Outside Diameter (in)	1.313 in
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	1,760 lb
Housing Coating	Powder Coated
Lubricant	EXXON RONEX MP STD
Bearing Centerline to Bolt Hole Center (in)	1.8125 in
Vibration Frequency Inner Ring Defect	0.0905 cps
Insert	SG216ELPA
Grease Fitting Thread Size	1/4-28
Cage Type	Ball Riding Retainer
Vibration Frequency Fundamental Train	0.0067 cps
Housing Width (in)	2.75 in

General Specifications

UPC	662327445522
Weight	1.66 LB
Packaged Length	5.63 IN
Packaged Width	3.19 IN
Packaged Height	1.81 IN
HTC	8483204040
Country of Origin	Mexico
