• Product Family: Ball Bearing; Line: Link-Belt Mounted

Dimensions

Foot Height (in)	0.91 in
Length Through Bore (in)	2.82 in
Overall Width (in)	6.38 in
Overall Height (in)	2.88 in
Overall Length (in)	6.38 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	2 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Seal Type	BUNA TRIPLE LIP SEAL
Bore Shape	Straight
Pilot Configuration	No Pilot
Outer Ring Land Profile	Standard
Cage Material	Molded fiber glass reinforced nylon
Housing Style	Flange Block
Rolling Element	Ball Bearing
Housing Type	Flange, Four Bolt
Misalignment Type	Static Only
Options	High Contamination
Housing Color	Black
Setscrew Torque (in-lbs)	430-460 in/lbs
Ability to Relubricate	Yes
Dynamic Load Rating (lb)	9,800 lb
Max Operating Temperature (C)	107 °C
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±1.5° Misalignment - Static Only
Grease Fitting Thread Size	1/8 NPT
Shaft Locking Type	Eccentric
Lubricant	EXXON RONEX MP STD
Locking Device Kit	W2325S
Vibration Frequency Fundamental Train	0.0068 cps
Maximum Speed (RPM)	500 rpm
Cage Type	Ball Riding Retainer
Housing Material	Cast Iron
Insert	YG232E3LK4
Lube Fill Percent	100% GREASE FILL
Vibration Frequency Outer Ring Defect	0.0680 cps
Vibration Frequency Roller Spin	0.0437 cps
Max Operating Temperature (F)	225 °F
Housing Coating	Powder Coated
Bearing Brand	LINK-BELT 200 SERIES BALL
Inner Ring Outside Diameter (in)	2.749 in
End Cap Available	No
Static Load Rating (lb)	6,570 lb
Bearing Type	Standard Duty
Size Code	211
Fixed vs. Expansion	Fixed
Radial Clearance	C3 STANDARD
Vibration Frequency Inner Ring Defect	0.0987 cps

General Specifications

UPC	662864826969
Weight	10.20 LB
HTC	8483204040
Country of Origin	Mexico
