• 1 15/16" Mounted Ball Bearing, Standard Duty, Cast Iron 4-Bolt Square Flange Block, Eccentric Cam Locking Collar, Triple Lip Contact Seal

Dimensions

Length Through Bore (in)	2.47 in
Foot Height (in)	0.75 in
Overall Height (in)	2.53 in
Overall Length (in)	5.63 in
Bore Diameter (in)	1.9375 in
Overall Width (in)	5.63 in
Bolt Size (in)	1/2 in
Bolt Spacing (in)	4.3750 in

Technical Specifications

Misalignment Type	Static Only
Rolling Element	Ball Bearing
Seal Type	Multi-Lip Contact Seal
Housing Color	Black
Bore Shape	Straight
Outer Ring Land Profile	Standard
Housing Type	Flange, Four Bolt
Pilot Configuration	No Pilot
Housing Style	Flange Block
Cage Material	Molded fiber glass reinforced nylon
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	290-325 in/lbs
Locking Collar Outside Diameter (in)	2.75 in
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Outer Ring Defect	0.0682 cps
Size Code	210
End Cap	Y2316N
Inner Ring Outside Diameter (in)	2.475 in
Misalignment Capability	±1.5° Misalignment - Static Only
Static Load Rating (lb)	5,220 lb
Vibration Frequency Roller Spin	0.0445 cps
Lubricant	EXXON RONEX MP STD
Housing Coating	Powder Coated
Radial Clearance	C3 STANDARD
Shaft Locking Type	Eccentric
Fixed vs. Expansion	Fixed
Max Operating Temperature (C)	107 °C
Dynamic Load Rating (lb)	7,920 lb
Vibration Frequency Inner Ring Defect	0.0985 cps
Insert	YG231E3L
Bearing Brand	LINK-BELT 200 SERIES BALL
Max Operating Temperature (F)	225 °F
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/8 NPT
End Cap Available	Yes
Locking Device Kit	W2315S
Housing Material	Cast Iron
Maximum Speed (RPM)	550 rpm
Cage Type	Ball Riding Retainer

General Specifications

UPC	662327037857
Weight	7.00 LB
Packaged Length	5.88 IN
Packaged Width	5.88 IN
Packaged Height	2.56 IN
HTC	8483204040
Country of Origin	Mexico
