• 7/8" Mounted Ball Bearing, Intermediate Duty, Cast Iron 4-Bolt Square Flange Block, Setscrew Locking, Single Lip Contact Seal, Nickel Plated Housing

Dimensions

Overall Height (in)	1.302 in
Foot Height (in)	0.44 in
Bore Diameter (in)	0.875 in
Length Through Bore (in)	1.178 in
Bolt Size (in)	7/16 in
Overall Length (in)	3.75 in
Overall Width (in)	3.75 in
Bolt Spacing (in)	2.75 in

Technical Specifications

Housing Type	Flange, Four Bolt
Misalignment Type	Static Only
Housing Construction	One Piece
Seal Type	Single Lip Contact Seal
Housing Color	Silver
Pilot Configuration	No Pilot
Cage Material	Molded fiber glass reinforced nylon
Outer Ring Land Profile	Standard
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	85 in/lbs
Ability to Relubricate	Yes
Max Operating Temperature (C)	107 °C
Maximum Speed (RPM)	6800 rpm
Fixed vs. Expansion	Fixed
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Set Screw
Bearing Insert Finish	Black Oxide
Bearing Brand	LINK-BELT 200 SERIES BALL
Vibration Frequency Fundamental Train	0.0067 cps
Static Load Rating (lb)	1,760 lb
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Coating	Nickel Plated
Radial Clearance	C3 STANDARD
Vibration Frequency Inner Ring Defect	0.0905 cps
Misalignment Capability	±1.5° Misalignment - Static Only
Inner Ring Outside Diameter (in)	1.313 in
Lubricant	MOBIL FM222 FOOD GRADE H1
Cage Type	Ball Riding Retainer
Max Operating Temperature (F)	225 °F
End Cap Available	No
Insert	SG214ELPAK8299A
Dynamic Load Rating (lb)	3,150 lb
Vibration Frequency Roller Spin	0.0387 cps
Housing Material	Cast Iron
Bearing Type	Intermediate Duty
Size Code	205
Grease Fitting Thread Size	1/4-28
Housing Width (in)	3.75 in

General Specifications

UPC	662327401481
Weight	2.10 LB
Packaged Length	4.00 IN
Packaged Width	4.00 IN
Packaged Height	2.00 IN
HTC	8483204040
Country of Origin	Mexico
