• 3 7/16" Mounted Spherical Roller Bearing, Top Angle Protected Screw Take-up Assembly, Single Setscrew Locking Collar, Clearance Seal

Dimensions

Bore Diameter (in)	3.4375 in
Overall Width (in)	5.19 in
Base to Center Height (in)	5.625 in
Overall Height (in)	11.75 in
Foot Height (in)	2 in
Overall Length (in)	40.25 in
Bolt Size (in)	3/4 in
Housing Width (in)	5.19 in
Channel Width (in)	4 in
Frame Width (in)	4.5 in
Frame Height (in)	11.75 in
Overall Rod Length (in)	38 in
Travel Length (in)	18 in
Frame Length (in)	40.25 in
Distance from Bearing Centerline to Housing Face (in)	1.72 in
Frame Bolt Hole Center to Bearing Centerline (in)	10 in
Bolt Spacing Width (in)	2 in
Bolt Spacing (in)	38 in
Length Through Bore (in)	4.39 in
Centerline to Outermost Bearing Face (in)	2.66 in

Technical Specifications

Static Load Rating (lb)	90,700 lb
Shaft Locking Type	Single Set Collar
End Cap	B456DTC
Housing Style	Take-Up Assembly
Radial Dynamic Load Capacity (lb)	62,300 lb
Misalignment Type	Dynamic
Housing Material	Cast Iron
Product	DSB22400XX
Fixed/Expansion	Fixed
Housing Construction	Solid
Radial Clearance	C0 STANDARD
Housing Type	Take-Up Assembly
Frame Material	Welded Steel
Rolling Element	Spherical Roller
Seal Type	Clearance Seal
Frame Type	Protected Screw Take-up Assembly
Cage Material	Steel
Series	Take-up Assemblies
Seal Kit	B456HS
Microlock Kit	B580MLK
Frame	ZNT1018
Allowable Working Load [2/3 Yield Strength] (lb)	8,400 lb
Setscrew Torque (in-lbs)	680 in/lbs
Adjusting Screw Thread Size	1 1/8-7 NC
Ability to Relubricate	Yes
Available Seal Type	E Lip Seal; H Labyrinth Seal; E7 Triple Lip Seal
Maximum Speed (RPM)	1650 rpm
Insert	B455L
Vibration Frequency Outer Ring Defect	0.1383 cps
Size Code	B456
Lubricant	EXXON RONEX MP STD
Max Operating Temperature (C)	107 °C
Replacement Take-up Block	DSB22455H
Misalignment Capability	±2.0° Misalignment - Dynamic
Locking Device Kit	B456SC
Housing Coating	POWDER COATED
Grease Fitting Thread Size	1/8 NPT
Max Operating Temperature (F)	225 °F
Vibration Frequency Inner Ring Defect	0.1784 cps
Vibration Frequency Roller Spin	0.0628 cps
Vibration Frequency Fundamental Train	0.0073 cps
Primary Seal	STEEL CLEARANCE SEAL

General Specifications

UPC	662327021955
Weight	112.75 LB
HTC	8483204080
