• IRIS® inverter rated insulation system meets NEMA MG1 Part 31. No lead lengths restrictions on 460V systems or less (as noted).
• Constant torque operation from 0 to base speed on vector drive.
• Double-shielded ball bearings provide longer service life.
• Normally closed thermostats (one per phase, Class F or H as noted).

Nameplate Specifications

Phase	3
Output HP	2 Hp
Output KW	1.5 kW
Voltage	230/460 V
Speed	1750 rpm
Service Factor	1.0
Frame	145TC
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	Thermostat
Efficiency	85.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.0/3.0 A
Power Factor	78
Duty	Continuous
Insulation Class	F
Design Code	INV
KVA Code	M
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6205
UL	Recognized
CSA	Y
CE	Y
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Duty
Starting Method	Inverter Only
Poles	4
Rotation	Reversible
Resistance Main	6.48 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Cast Iron
Shaft Type	T
Overall Length	14.68 in
Frame Length	6.25 in
Shaft Diameter	0.875 in
Shaft Extension	2.12 in
Assembly/Box Mounting	F1/F2 CAPABLE
Inverter Load	CONSTANT 1000:1

General Specifications

UPC	722856024862
Weight	85.00 LB
Packaged Length	15.82 IN
Packaged Width	12.56 IN
Packaged Height	9.38 IN
HTC	8501.52.4000
Country of Origin	Mexico
