• Double-shielded bearings extend the service life of the motor.
• EXXON® Polyrex® EM Grease supports extreme temperatures between -20°F(-29 ˚ C) and +350°F(+177˚C).
• Shaft flingers protect bearings from damage caused by dirt and rain.
• Condensation drains allow the motor to expel and drain built-up moisture.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.25 & 0.08 Hp
Output KW	0.19 & 0.06 kW
Voltage	115 & 115 V
Speed	1725 & 1140 rpm
Service Factor	1.0 & 1.0
Frame	48
Enclosure	Totally Enclosed Air Over
Thermal Protection	Automatic
Efficiency	62 & 35.2 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.95 & 2.25 A
Power Factor	68
Duty	Continuous
Insulation Class	B
Design Code	2VT
KVA Code	R
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	2

Technical Specifications

Electrical Type	Split Phase
Starting Method	Across The Line
Poles	4//6
Rotation	Selective Counterclockwise
Resistance Main	0 Ohms
Mounting	Round - Extended Studs
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 48
Overall Length	11.09 in
Frame Length	6.50 in
Shaft Diameter	0.500 in
Shaft Extension	2.59 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856028563
Weight	17.00 LB
Packaged Length	13.25 IN
Packaged Width	7.00 IN
Packaged Height	6.94 IN
HTC	8501.40.4040
Country of Origin	Mexico
