• Automatic reset thermal(as noted) protector prevents overheating.
• Shielded ball bearings extend the service life of the motor.
• Class B insulation protects motor for a maximum temperature rating.
• Suitable for indoor or outdoor applications(as noted).
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	230 V
Speed	825 rpm
Service Factor	1
Frame	48Y
Enclosure	Open Air Over
Thermal Protection	Automatic
Efficiency	57.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.8 A
Power Factor	72.3
Duty	Continuous
Insulation Class	B
Design Code	NO DESIGN CODE
KVA Code	D
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	10
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor
Starting Method	Across The Line
Poles	8
Rotation	Selective Counterclockwise
Resistance Main	0 Ohms
Mounting	Resilient Rings
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Overall Length	12.22 in
Frame Length	5.25 in
Shaft Diameter	0.500 in
Shaft Extension	5.53 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856049087
Weight	17.00 LB
Packaged Length	13.25 IN
Packaged Width	7.00 IN
Packaged Height	6.94 IN
HTC	8501.40.4040
Country of Origin	Mexico
