• 303 stainless steel gearbox output shaft
• Frame, end shields, armature and interior components protected by enamel and polyester compounds for resistance to moisture, acids, alkalies and oil
• Cast conduit box with threaded conduit holes and Nitrile gaskets keep water out
• Conduit box cover is made from 304 stainless steel
• For any condensation that may accumulate inside the motor, a one-way stainless steel vapor vent is provided
• All hardware is stainless steel; Painted with white epoxy for superior corrosion resistance and protection
• Machined fits between the end bells and motor frame are sealed with gaskets; Thru-bolt heads and nuts sealed with fiber washers
• O-rings under each threaded brush cover; Worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation
• Precision PMAChined aluminum gear housing; Lubrication is permanent with an oil bath; Gearbox has all ball bearings
• Output shaft is field interchangeable from left hand to right hand style by reassembly; Double output shaft available as a factory option

Nameplate Specifications

Output HP	0.25 Hp
Output KW	0.19 kW
Voltage	90 V
Speed	62 rpm
Service Factor	1
Frame	32
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	30.5 %
Ambient Temperature	40 °C
Current	3.7 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6201
Opp Drive End Bearing Size	6201
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Right Angle
Overall Length	12.86 in
Frame Length	5.94 in
Shaft Diameter	0.625 in
Shaft Extension	1.8 in
Torque	135 LB-IN

General Specifications

UPC	691720346181
Weight	17.00 LB
Packaged Length	16.50 IN
Packaged Width	7.68 IN
Packaged Height	6.69 IN
Country of Origin	United States of America
