• 303 Stainless steel shaft resists corrosion
• Lubricated spring loaded contact seals prevent moisture from entering the motor
• Double sealed, Oversize bearings with high temp lubricant
• Exterior and interior components protected against moisture,acids, alkalies and oil
• Cast conduit box for superior sealing includes: - Threaded conduit entrance - Drain holes - Nitrile gaskets - 304 stainless steel conduit box cover - Stainless steel hardware
• USDA Approved white epoxy finish
• Nylon seals at bolt heads for superior sealing
• O ring sealed brush covers

Nameplate Specifications

Output HP	0.13 Hp
Output KW	0.10 kW
Voltage	90 V
Speed	31 rpm
Service Factor	1
Frame	31
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	57.1 %
Ambient Temperature	40 °C
Current	1.6 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6201
Opp Drive End Bearing Size	6201
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	11.94 in
Frame Length	4.94 in
Shaft Diameter	0.625 in
Shaft Extension	1.5 in
Torque	220 LB-IN

General Specifications

UPC	691720346310
Weight	16.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
