• USDA-approved epoxy painted motors
• NEMA motors
• Three phase
• BISSC approved
• Double lip contact seals and v-ring seals used for shaft seals
• Full fact nameplate is laser etched on the motor frame
• UL recognized and CSA certified
• LEESON® motors. Motors and solutions at our core™
• Operational at 208-230/460 V @60HZ. Nameplate image may vary from actual product.

Nameplate Specifications

Phase	3
Output HP	0.75 & 0.50 Hp
Output KW	0.56 & 0.37 kW
Voltage	230/460 & 190/380 V
Speed	3450 & 2850 rpm
Service Factor	1.15 & 1.15
Frame	56J
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	75.5 & 68 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	2.4/1.2 & 2.2/1.1 A
Power Factor	78
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	J
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Reversible
Resistance Main	28 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	J
Overall Length	11.37 in
Frame Length	5.00 in
Shaft Diameter	0.625 in
Shaft Extension	2.44 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720348970
Weight	24.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
