• USDA-approved white epoxy finish ensures resistance and protection against caustic cleaning solutions.
• Sealed bearings shut out contaminants that lead to bearing failure.
• Stainless steel output shaft seals protect against external contaminants.
• Cast, white epoxy conduit boxes house electrical wiring.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	230/460 V
Speed	3450 rpm
Service Factor	1.15
Frame	56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	77 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.6/1.3 A
Power Factor	85
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	L
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	11.56 in
Frame Length	6.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720011683
Weight	38.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
