• Pressure encapsulation technology - winding end coils totally encapsulated
• 303 Stainless shaft
• Double sealed bearings
• FDA approved white finish coat
• Stainless laser etched nameplate
• 304 stainless steel conduit box cover and fan cover
• Repositionable drain plugs for use in multiple mounting positions
• Nylon seals at bolt heads for superior sealing
• Machined fits throughout
• USDA approved white epoxy finish

Nameplate Specifications

Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	180 V
Speed	1750 rpm
Service Factor	1.0
Frame	S56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	81.7 %
Ambient Temperature	40 °C
Current	2.5 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Rigid C base
Overall Length	13.63 in
Frame Length	7.47 in
Shaft Diameter	0.625 in
Shaft Extension	2.06 in
Torque	18 LB-IN

General Specifications

UPC	691720006795
Weight	46.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
