• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Class B or F Insulation protects motor for a maximum temperature rating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• LEESON® motors. Motors and solutions at our core™
• Operational at 208-230/460 V @60HZ. Nameplate image may vary from actual product.

Nameplate Specifications

Phase	3
Output HP	0.50 & 0.50 Hp
Output KW	0.37 & 0.37 kW
Voltage	230/460 & 190/380 V
Speed	1725 & 1425 rpm
Service Factor	1.15 & 1.15
Frame	S56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Thermostat
Efficiency	77 & 77 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	1.8/.9 & 2/1 A
Power Factor	69
Duty	Continuous
Insulation Class	F
Design Code	NO DESIGN CODE
KVA Code	M
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	9.166 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	10.69 in
Frame Length	6.00 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 10:1

General Specifications

UPC	691720006023
Weight	21.00 LB
Packaged Length	13.75 IN
Packaged Width	7.88 IN
Packaged Height	8.75 IN
Country of Origin	Mexico
