• Full stainless steel exterior promotes resistance to water and chemical corrosion.
• Double sealed bearings extend the lifetime of the motor by combating early signs of bearing failure.
• Stainless steel output shaft seals protect against external contaminants.
• Insulation systems deliver superior protection against voltage spikes.
• LEESON® motors. Motors and solutions at our core™
• Operational at 208-230/460 V @60HZ. Nameplate image may vary from actual product.

Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	230/460 V
Speed	1760 rpm
Service Factor	1.15
Frame	143TC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Thermostat
Efficiency	85.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.2/1.6 A
Power Factor	68.5
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	N
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	12.96 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Stainless Steel
Shaft Type	T
Overall Length	12.72 in
Frame Length	7.00 in
Shaft Diameter	0.875 in
Shaft Extension	2.12 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 6:1

General Specifications

UPC	691720052488
Weight	36.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
