• UL recognized component listing and CSA certification ensures the product is safe for use.
• Class F Insulation protects motor for a maximum temperature rating.
• Cast iron and streel frame construction for durability.
• Internal corrosion protection extends motor life.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	2 Hp
Output KW	1.5 kW
Voltage	460 V
Speed	1740 rpm
Service Factor	1.15
Frame	145T
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	86.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.0 A
Power Factor	78
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	N
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	56
Number of Speeds	1
Hazardous Location	DIVISION 2 T2B

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	6.51 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Cast Iron
Shaft Type	T
Overall Length	11.43 in
Frame Length	6.25 in
Shaft Diameter	0.875 in
Shaft Extension	2.56 in
Assembly/Box Mounting	F1/F2 CAPABLE
Inverter Load	CONSTANT 10:1

General Specifications

UPC	722856055040
Weight	63.55 LB
Packaged Length	15.50 IN
Packaged Width	12.25 IN
Packaged Height	9.38 IN
HTC	8501.52.4000
Country of Origin	Mexico
