• Fully variable speed & dual rotation capability to benefit custom cooking cycles.
• High, flat efficiency curve to reduce energy consumption and benefit Energy Star recognition.
• Power dense & compact enabling smaller equipment & space savings.
• Tethered drive enables flexibility to fit your equipment needs.
• Sealed for life bearings and stainless steel shaft extension for commercial restaurant environments.
• Visual LED and accessible data logging for fast and easy technician diagnostics.
• IoT connectable through serial communication enabling monitoring, predictive alarms, & diagnostics for reduced downtime, maintenance, and optimized operations.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	115/230/277 V
Speed	1800 rpm
Service Factor	1.00
Frame	48Z
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	80 %
Ambient Temperature	65 °C
Frequency	60 Hz
Current	6.0/3.5/2.9 A
Power Factor	60
Duty	Continuous
Insulation Class	F
Design Code	No Design Code
Drive End Bearing Size	6201
Opp Drive End Bearing Size	6201
UL	Recognized
CSA	N
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	AC Permament Magnet
Starting Method	Across The Line
Poles	10
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Round
Motor Orientation	Horizontal Or Shaft Down
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720115633
Weight	8.80 LB
Packaged Length	7.50 IN
Packaged Width	7.36 IN
Packaged Height	7.30 IN
Country of Origin	Thailand
