• Single source, performance matched EC motor with pre-programmed control designed for simple install and immediate use
• Durable & reliable - totally enclosed, IP55 ingress protection, class F insulation, and potted control for resiliance in tough barn environments
• Fully variable speed with high, flat efficiency curve reduces energy consumption leading to year over cost savings and benefit for utility rebates
• NEMA 56 Frame C-face, foot mount, and shaft extension geometry
• Suitable for horizontal, vertical shaft down, and vertical shaft up orientation
• Visual LED and accessible data logging for fast and easy technician diagnostics
• IoT connectable through serial communication enabling monitoring, predictive alarms, & diagnostics for reduced downtime, maintenance, and optimized operations
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.75 Hp
Output KW	0.56 kW
Voltage	115/230/277 V
Speed	900 rpm
Service Factor	1.00
Frame	S56C
Enclosure	Totally Enclosed Air Over
Thermal Protection	No Protection
Efficiency	85 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	8.4/5.0/4.0 A
Power Factor	63
Duty	Continuous
Insulation Class	F
Design Code	No Design Code
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	N
CE	N
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	AC Permament Magnet
Starting Method	Across The Line
Poles	10
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal Or Up Or Down
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720115640
Weight	23.00 LB
Packaged Length	13.40 IN
Packaged Width	8.41 IN
Packaged Height	7.45 IN
Country of Origin	Thailand
