• High-efficiency design utilizes low-loss steel laminations for optimum power and performance.
• Inverter rated insulation system exceeds NEMA MG1 Part 31. No lead lengths restrictions on 460V systems or less (as noted).
• IP55 weatherproof enclosure for use in a wide range of applications.
• Double-shielded bearings extend the service life of the motor.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	2 & 2 Hp
Output KW	1.5 & 1.5 kW
Voltage	230/460 & 200/400 V
Speed	1745 & 1435 rpm
Service Factor	1.15 & 1.15
Frame	90L
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	87.5 & 85.5 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	5.4/2.7 & 6.4/3.2 A
Power Factor	78.4
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	J
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6205
UL	Recognized
CSA	Y
CE	Y
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Aluminum
Shaft Type	IEC
Overall Length	12.83 in
Frame Length	7.08 in
Shaft Diameter	1.000 in
Shaft Extension	1.96 in
Assembly/Box Mounting	F3
Inverter Load	CONSTANT 20:1

General Specifications

UPC	722856027405
Weight	45.00 LB
Packaged Length	14.76 IN
Packaged Width	9.65 IN
Packaged Height	10.63 IN
HTC	8501.52.4000
Country of Origin	China
