• All exterior components are 300-series stainless steel
• Double-sealed bearings are pre-lubricated with moisture-resistant high temperature grease for long life
• Windings are immersed and cured in polyester insulating varnish for extra moisture-resistance
• WASHGUARD efficiencies meet EPAct mandates for non-exempt motors when tested without shaft seals
• All Washdown Duty motors have Class F Insulation
• Ease to clean construction is BISSC Certified for bakery applications
• Washdown Duty
• Nameplate etched in frame; Full fact nameplate is laser etched on the motor frame
• Operational at 208-230/460 V @60HZ. Nameplate image may vary from actual product.

Nameplate Specifications

Phase	3
Output HP	1 & 0.75 Hp
Output KW	0.75 & 0.56 kW
Voltage	230/460 & 190/380 V
Speed	1750 & 1450 rpm
Service Factor	1.15 & 1.15
Frame	56HC
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	85.5 & 84 %
Ambient Temperature	40 °C
Frequency	60 & 50 Hz
Current	2.8/1.4 & 2.6/1.3 A
Power Factor	77.7
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	L
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6205
UL	Recognized
CSA	Y
CE	Y
IP Code	56
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Stainless Steel
Shaft Type	NEMA 56
Overall Length	18.01 in
Frame Length	9.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 6:1

General Specifications

UPC	691720102862
Weight	73.00 LB
Packaged Length	22.88 IN
Packaged Width	10.56 IN
Packaged Height	9.88 IN
Country of Origin	United States of America
