• All exterior components are 300-series stainless steel; All sealing components are Viton® for superior chemical resistance
• End shields are O-ring sealed to the frame; Double lip shaft seals on both ends of TEFC motors (shaft end only on TENV motors)
• Double-sealed bearings are pre-lubricated with moisture-resistant high temperature grease for long life
• Interior coatings applied to rotor and stator protect against corrosion; Ease to clean construction is BISSC Certified for bakery applications
• Removable hydrophobic breathers in opposite shaft end bell and conduit box equalize pressure without allowing moisture to enter
• LEESON’s exclusive IRIS™ Inverter-Rated Insulation System provides extra protection and long life, especially in inverter-driven applications
• All Washdown Duty motors have Class F Insulation
• LEESON® motors. Motors and solutions at our core™
• Full fact nameplate is laser etched on the motor frame

Nameplate Specifications

Output HP	1 Hp
Output KW	0.75 kW
Voltage	180 V
Speed	1750 rpm
Service Factor	1.0
Frame	ZS56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	85.3 %
Ambient Temperature	40 °C
Current	5.0 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Round
Overall Length	13.87 in
Frame Length	9.63 in
Shaft Diameter	0.625 in
Shaft Extension	2.05 in
Torque	36 LB-IN

General Specifications

UPC	691720343142
Weight	59.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
