• End shields are O-ring sealed to the frame
• Double lip shaft seals on both ends of TEFC motors (shaft end only on TENV motors)
• Double-sealed bearings are pre-lubricated with moisture-resistant high temperature grease for long life
• Interior coatings applied to rotor and stator protect against corrosion
• New conduit box mounting system provides optimum sealing
• Windings are immersed and cured in polyester insulating varnish for extra moisture-resistance
• All Washdown Duty motors have Class F Insulation
• LEESON’s exclusive IRIS™ Inverter-Rated Insulation System provides extra protection and long life, especially in inverter-driven applications
• All sealing components are Viton® for superior chemical resistance
• Full fact nameplate is laser etched on the motor frame

Nameplate Specifications

Output HP	0.25 Hp
Output KW	0.19 kW
Voltage	90 V
Speed	1750 rpm
Service Factor	1.0
Frame	NS56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	67.5 %
Ambient Temperature	40 °C
Current	3.1 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Round
Overall Length	11.81 in
Frame Length	6.13 in
Shaft Diameter	0.625 in
Shaft Extension	2.05 in
Torque	9 LB-IN

General Specifications

UPC	691720343036
Weight	38.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
