• All exterior components are 300-series stainless steel
• All sealing components are Viton® for superior chemical resistance
• Double lip shaft seals on both ends of TEFC motors (shaft end only on TENV motors)
• Double-sealed bearings are pre-lubricated with moisture-resistant high temperature grease for long life
• Windings are immersed and cured in polyester insulating varnish for extra moisture-resistance
• All Washdown Duty motors have Class F Insulation
• New conduit box mounting system provides optimum sealing
• Ease to clean construction is BISSC Certified for bakery applications
• LEESON® motors. Motors and solutions at our core™
• Full fact nameplate is laser etched on the motor frame

Nameplate Specifications

Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	180 V
Speed	1750 rpm
Service Factor	1.0
Frame	US56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	73.7 %
Ambient Temperature	40 °C
Current	1.9 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Rigid C base
Overall Length	12.81 in
Frame Length	7.25 in
Shaft Diameter	0.625 in
Shaft Extension	2.05 in
Torque	12 LB-IN

General Specifications

UPC	691720342923
Weight	44.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
