• Double-shielded bearings extend the service life of the motor.
• EXXON® Polyrex® EM Grease supports extreme temperatures between -20°F(-29 ˚ C) and +350°F(+177˚C).
• Shaft flingers protect bearings from damage caused by dirt and rain.
• Condensation drains allow the motor to expel and drain built-up moisture.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	115/230 V
Speed	1725 rpm
Service Factor	1
Frame	48Z
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	Automatic
Efficiency	65.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Power Factor	0
Duty	Continuous
Insulation Class	B
KVA Code	F
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Yes
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor(PSC)
Starting Method	N/R
Poles	4
Rotation	Counterclockwise
Mounting	Round
Motor Orientation	ANY
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Overall Length	10.18 in
Frame Length	5.41 in
Shaft Diameter	0.500 in
Shaft Extension	2.5 in

General Specifications

UPC	722856028549
Weight	15.00 LB
Packaged Length	13.69 IN
Packaged Width	7.13 IN
Packaged Height	7.50 IN
Country of Origin	Mexico
