• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double shielded ball bearings provide longer service life.
• Continuous or continuous air over duty design allows consistent operation at the rated power(as noted).
• Various mounting configurations (as noted).
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.20 Hp
Output KW	0.15 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.0
Frame	48N
Enclosure	Semi Enclosed
Thermal Protection	Manual
Efficiency	61.0 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.0/1.5 A
Power Factor	77.3
Duty	Continuous
Insulation Class	B
Design Code	NO DESIGN CODE
KVA Code	L
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	10
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Selective Clockwise
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 48
Overall Length	8.35 in
Frame Length	4.75 in
Shaft Diameter	0.500 in
Shaft Extension	1.97 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856041555
Weight	14.00 LB
Packaged Length	11.35 IN
Packaged Width	9.50 IN
Packaged Height	10.57 IN
HTC	8501.40.4040
Country of Origin	Mexico
