• 10:1 Variable torque, Constant torque speed range as listed below
• IRIS® Class F insulation system
• 1.15 Service Factor on sinewave, 1.0 Service Factor on IGBT power
• Double sealed ball bearings
• 303 Stainless steel shaft with spring loaded contact seals in each endshield (Drive end only on TENV motors)
• Stainless steel conduit box cover, nameplate, fan guard (TEFC only) and hardware
• Cast oversized conduit box with high temperature nitrile gaskets and threaded entrance
• Plugged drain holes in each endshield for all angle mounting
• Internal corrosion resistant coatings on frame, base, endshields, rotor and stator
• As of 4/30/24 this product is now listed as LEESON® brand due to <a href="https://investors.regalrexnord.com/investors/ir-news/press-release-details/2024/Regal-Rexnord-Corporation-Closes-The-Sale-Of-Its-Industrial-Motors--Generators-Business-To-WEG/default.aspx">the divestiture of the Industrial Business.</a>

Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	208-230/460 V
Speed	1740 rpm
Service Factor	1.15
Frame	143TC
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	80 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.2/1.6 A
Power Factor	75
Duty	Continuous
Insulation Class	F
Design Code	B
KVA Code	M
Drive End Bearing Size	6205
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	55
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Resistance Main	16 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	11.62 in
Shaft Diameter	0.875 in
Shaft Extension	1.99 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	722856029102
Weight	35.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
HTC	8501.52.4000
Country of Origin	United States of America
