• Precision machined in-line steel gears.
• Permanent split capacitor design rated for 115/230 VAC 60/50 HZ input.
• Lubrication is permanent semi-fluid grease, reducing possibility of leakage.
• Output shafts have needle bearings to handle high load capacities.

Nameplate Specifications

Phase	1
Output HP	0.16 Hp
Output KW	0.12 kW
Voltage	115 V
Speed	90 rpm
Service Factor	1
Frame	38
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.1/1.1 A
Duty	Continuous
Insulation Class	F
KVA Code	D
Drive End Bearing Size	6201
Opp Drive End Bearing Size	6201
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	12.13 in
Frame Length	5.88 in
Shaft Diameter	0.625 in
Shaft Extension	1.5 in
Torque	103 LB-IN

General Specifications

UPC	691720092170
Weight	19.00 LB
Packaged Length	16.50 IN
Packaged Width	7.68 IN
Packaged Height	6.69 IN
Country of Origin	United States of America
