• Rugged die cast aluminum gear housing supplies maximum gear and bearing support.
• Performance matched for continuous duty service.
• Heavy duty industrial oil seals keep lubricant in and dirt out.
• All gearing designed and rated to AGMA Class 9 Standards, and to withstand momentary shock overload of 200%.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Output HP	0.13 Hp
Output KW	0.10 kW
Voltage	90 V
Speed	14 rpm
Service Factor	1.0
Frame	34
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	47.2 %
Ambient Temperature	40 °C
Current	1.0 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6201
Opp Drive End Bearing Size	608
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	11.31 in
Frame Length	4.06 in
Shaft Diameter	0.750 in
Shaft Extension	1.625 in
Torque	341 LB-IN

General Specifications

UPC	691720091838
Weight	12.00 LB
Packaged Length	16.50 IN
Packaged Width	7.68 IN
Packaged Height	6.69 IN
Country of Origin	United States of America
