• Designed with the exclusive Inverter Rated Insulation System (IRIS)
• Provides superior protection against voltage spikes induced by variable frequency drives
• Double shielded motor ball bearings
• Needle bearings in the parallel shaft gearboxes
• Steel conduit box provided as Standard
• Finished in high gloss hardened black enamel paint

Nameplate Specifications

Phase	3
Output HP	0.07 Hp
Output KW	0.05 kW
Voltage	208-230 V
Speed	57 rpm
Service Factor	1
Frame	31
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	0.40 A
Duty	Continuous
Insulation Class	F
KVA Code	H
Drive End Bearing Size	6000
Opp Drive End Bearing Size	R6
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	10.83 in
Frame Length	5.75 in
Shaft Diameter	0.500 in
Shaft Extension	1 in
Torque	56 LB-IN

General Specifications

UPC	691720100332
Weight	10.00 LB
Packaged Length	15.25 IN
Packaged Width	7.13 IN
Packaged Height	5.63 IN
Country of Origin	United States of America
