• IRIS® Inverter-rated insulation system provides superior protection against voltage spikes induced by variable frequency drives.
• Double-shielded bearings extend the service life of the motor.
• Output shafts have needle bearings to handle high load capacities.
• Finished in high-gloss hardened black enamel paint.

Nameplate Specifications

Phase	1
Output HP	0.07 Hp
Output KW	0.05 kW
Speed	94 rpm
Service Factor	1
Frame	31
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	0.90 A
Duty	Continuous
Insulation Class	F
KVA Code	C
Drive End Bearing Size	6000
Opp Drive End Bearing Size	6000
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	9.62 in
Frame Length	4.63 in
Shaft Diameter	0.500 in
Shaft Extension	1 in
Torque	36 LB-IN

General Specifications

UPC	691720091302
Weight	10.00 LB
Packaged Length	15.25 IN
Packaged Width	7.13 IN
Packaged Height	5.63 IN
Country of Origin	United States of America
