• Permanent split capacitor design rated for 115VAC 60 HZ input
• Precision machined in-line steel gears
• First stage steel helical gear followed by spur-type gears
• Lubrication is permanent semi-fluid grease, reducing possibility of leakage
• Output shafts have needle bearings for high load capacities
• Shafts are hardened steel
• Optional conduit box and PZ gearmotor mounting bracket available

Nameplate Specifications

Phase	1
Output HP	0.06 Hp
Output KW	0.04 kW
Voltage	115 V
Speed	9 rpm
Service Factor	1
Frame	31
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	0.90 A
Duty	Continuous
Insulation Class	F
KVA Code	C
Drive End Bearing Size	6000
Opp Drive End Bearing Size	6000
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	10.42 in
Frame Length	4.63 in
Shaft Diameter	0.500 in
Shaft Extension	1 in
Torque	100 LB-IN

General Specifications

UPC	691720091265
Weight	10.00 LB
Packaged Length	16.50 IN
Packaged Width	7.68 IN
Packaged Height	6.69 IN
Country of Origin	United States of America
