• Performance matched for continuous duty service.
• Precision machined in-line steel gears.
• Lubrication is permanent semi-fluid grease, reducing possibility of leakage.
• Output shafts have needle bearings to handle high load capacities.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Output HP	0.13 Hp
Output KW	0.10 kW
Voltage	180 V
Speed	170 rpm
Service Factor	1.0
Frame	30
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	64.6 %
Ambient Temperature	40 °C
Current	0.66 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6000
Opp Drive End Bearing Size	6000
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	11.45 in
Frame Length	4.91 in
Shaft Diameter	0.625 in
Shaft Extension	1.5 in
Torque	43 LB-IN

General Specifications

UPC	691720091074
Weight	13.00 LB
Packaged Length	16.50 IN
Packaged Width	7.68 IN
Packaged Height	6.69 IN
Country of Origin	United States of America
