• Compact and space saving design.
• External access to brushes supprots easy replacement for prolonged motor life.
• Double-shielded ball bearings provide longer service life.
• Reversible rotation allows greater flexibility within the application.
• High starting torque on start-up, to achieve a higher starting load required in sub-fractional applications.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Output HP	0.13 Hp
Output KW	0.10 kW
Voltage	90 V
Speed	3500 rpm
Service Factor	1.0
Frame	31
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	68 %
Ambient Temperature	40 °C
Current	1.5 A
Duty	Continuous
Insulation Class	H
Drive End Bearing Size	6201-13
Opp Drive End Bearing Size	6201-13
UL	Recognized
CSA	Y
CE	Y

Technical Specifications

Rotation	Reversible
Mounting	Round
Overall Length	7.45 in
Frame Length	3.50 in
Shaft Diameter	0.500 in
Shaft Extension	1.5 in
Torque	36 OZ-IN

General Specifications

UPC	691720090862
Weight	7.00 LB
Packaged Length	16.50 IN
Packaged Width	7.68 IN
Packaged Height	6.69 IN
Country of Origin	United States of America
