• UL recognized component listing and CSA certification ensures the product is safe for use.
• Class B or F Insulation protects motor for a maximum temperature rating.
• Double-shielded bearings extend the service life of the motor.
• Rolled steel, aluminum, and cast iron frame materials promote rugged construction.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	3
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	575 V
Speed	1725 rpm
Service Factor	1.25
Frame	56
Enclosure	Drip Proof
Thermal Protection	No Protection
Efficiency	78.2 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	0.70 A
Power Factor	55.5
Duty	Continuous
Insulation Class	B
Design Code	B
KVA Code	LATER
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	Y
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Inverter Rated
Starting Method	Line Or Inverter
Poles	4
Rotation	Reversible
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	11.32 in
Frame Length	5.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in
Assembly/Box Mounting	F1 ONLY
Inverter Load	CONSTANT 2:1

General Specifications

UPC	691720088845
Weight	30.00 LB
Packaged Length	15.63 IN
Packaged Width	8.63 IN
Packaged Height	8.63 IN
Country of Origin	Mexico
