• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Double-shielded bearings extend the service life of the motor.
• Single and three phase, TEFC, TEAO, and ODP construction.
• Overload protection prevents motor from overheating.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	1.50 Hp
Output KW	1.1 kW
Voltage	115/230 V
Speed	3475 rpm
Service Factor	1
Frame	143T
Enclosure	Totally Enclosed Air Over
Thermal Protection	Automatic
Efficiency	70 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	16.8/8.4 A
Power Factor	79
Duty	Continuous
Insulation Class	F
Design Code	NO DESIGN CODE
KVA Code	H
Drive End Bearing Size	205
Opp Drive End Bearing Size	203
UL	Recognized ( Not Protector)
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Selective Counterclockwise
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	11.49 in
Frame Length	7.56 in
Shaft Diameter	0.875 in
Shaft Extension	2.25 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720021927
Weight	35.00 LB
Packaged Length	15.82 IN
Packaged Width	12.56 IN
Packaged Height	9.38 IN
Country of Origin	Mexico
